Comply with ANSI/EIA RS-310-D,IEC297-2,DIN41491,PART1,DIN41494,PART7,GB/3047.2-92
Feature:
u "U"shaped rails 3"x1 1/4"tapped both front and rear with EIA compliant RMS space
u Base with perforated holes for floor anchoring
u Reinforced angled top brace supports
u A series accessories on your option, such us shelves,fan panel,cable management and so on
u Both mounting post with U mark
u Meets or exceeds EIA-310D standards
u Height from 16U-45U, they are optional
u Easy to assemble
u Flat package,easy to carry and saving space
Loading Capacity:
Static loading is
|
Part |
Thickness of Aluminum |
Surface finish |
|
Mounting post |
|
Degreasing, pickling, phosphoric, dip-coat primed, powder coat |
|
Base angle |
|
Degreasing, pickling, phosphoric, dip-coat primed, powder coat |
|
Top angle |
|
Degreasing, pickling, phosphoric, dip-coat primed, powder coat |
Main Specification(mm)
|
U |
width*depth*height |
|
|
16U |
520*76*853 |
|
|
CYAC-01-20W5D7 |
20U |
520*76*1030 |
|
CYAC-01-28W5D7 |
28U |
520*76*1385 |
|
CYAC-01-45W5D7 |
45U |
520*76*2140 |
